Dash Cam 3 Channel 2K+1080P+1080P Front Inside Rear

Front 2K + inside 1080P + Rear 1080p Dashcam

This product adopts high performance chipsetto provide high defnition vide.with seamless motion picture and Rohssupports FHD 1080P and 2K QHD video recording. Please read this manual carefullybefore use and keep itin a safe place.

Menu
1. Short press to open menu
2. Long press to enter into playback mode

UP
1. In System setting mode, short press to switch the settings
2. In video mode, short press to switch the lens real-time view
3. In playback mode, short press to choose the file which you want to playback
4. Long press to turn on / off WIFI

Down
1. in System setting mode, short press to switch the settings
2. in playback mode, short press to choose the file which you want to playback
3. In video mode, short press to turn on /off audio

Function interface
Recording video
System setting
Smart Driving : ADAS、BSD、LCA
Resolution : 2K、1080P
Recording Mode 3 Recording
Video Resolution: 2160*1440P@30fps+ 1920*1080P@30fps+ 1920*1080P@30fps
Photo Resolution: VGA/1M/2M/3M/5M
Video Format: TS
Picture Format: JPEG
Audio Format: PCM(0X1)-PCM
Camera: Sensor Chip SC2336 Lens: 2G+2P (lens + IR filter)
Aperture F=1.8
Viewing Angle D:124° H:105° V:56°
WIF Function: Support 2.4G
Display Size: 3.16 "IPS HD Screen
Maximum Power Consumption: 560mA(5V)
Power Supply and Charging Device: Input 12-24V, Output 5V/1.5A, TYPE-C, Cable length 3.5M, No load above 5.4M. Power supply and charging device: Input 12-24V, output 5V/1.5A, TYPE-C, cable length 3.5M, no-load not higher than 5.4V, load 4.6-5.2V
Language: English/French/Spanish/Germany/Italian/Russia/Japanese/Chinese
Dimensions: 118x68.5x46.6mm

Note: Formatting will delete all the files (including locked files) in the memory cardafter formatting , the files will not be recoverable, please copy importantfilesbefore format.

Package included:
1x Dashcam
1x Rearviewlens
1x Car charger
1x User Manual
